Features
1. The barrel and screw of the Shrinkable Film Making Machine are made of high-quality alloy steel, which has high hardness and is durable.
2. The auxiliary machine is equipped with a platform workbench, which is easy to operate, and is equipped with a device to stabilize the film.
3. The coiling device is driven by a torque motor, which can achieve uniform coiling and convenient coil replacement.
4. We use stronger steel plate as the body to make the machine more stable.
5. The service life of the hard surface gearbox can reach more than 5 years.
6. The motor is selected from Siemens, which conforms to the CE standard and has a life span of more than 10 years.
7. Simple operation, one worker can control 3 machines.
8. Temperature controller: Omron brand
9. Inverter: LG brand
Serve
1. Installation service:
Installation is included with all new machine purchases. We will provide you with operating know-how, and provide support for the installation, commissioning and operation of the machine, and guide you on how to use the machine well.
2. After-sales service:
We provide preventive maintenance and after-sales service. Therefore, we provide comprehensive maintenance to prevent equipment problems. We also offer a one-year warranty.
Specification
| Shrinkable Film Making Machine | ||||||
Model | SJ-50/FM600 | SJ-55FM800 | SJ-60/FM1000 | SJ-65/FM1200 | SJ-80/FM1500 | SJ-100/FM2000 |
Screw Diamete | 50mm | 55mm | 60mm | 65mm | 80mm | 100mm |
Screw Ratio | L/D28:1 | L/D28:1 | L/D28:1 | L/D28:1 | L/D28:1 | L/D28:1 |
Screw Speed | 10-100r/min | 10-100r/min | 10-100r/min | 10-100r/min | 10-100r/min | 10-100r/min |
Power of Main Motor | 11KW | 15KW | 18.5KW | 22kw | 30KW | 55KW |
Specification of Die head | 50-100mm | 100-150mm | 100-180mm | 120-220mm | 150-300mm | 500mm |
Rotational Mode of Die | Continuous rotate | Continuous rotate | Continuous rotate | Continuous rotate | Continuous rotate | Continuous rotate |
Film Width | 600mm | 800mm | 1000mm | 1200mm | 1500mm | 2000mm |
Thickness | 0.01-0.10mm | 0.01-0.10mm | 0.01-0.10mm | 0.01-0.10mm | 0.01-0.10mm | 0.01-0.10mm |
Overall Dimension | 5000x2000x3800mm | 6000x2000x4000mm | 6500x2200x4500mm | 6800x2400x4800mm | 7000x2700x5500mm | 8000x3200x7600mm |
Why choose us?
- We offer a wide range of customization options to ensure that each machine meets our client’s needs.
- While pursuing the economic benefits, we also take the initiative to pursue the social benefits and take the social responsibility of the enterprise.
- Our machines are designed for durability, reducing the need for regular maintenance and repairs.
- Our company implements independent operation and self-financing in accordance with market-oriented and enterprise-oriented operation and management.
- Our team is made up of experts in the field, dedicated to producing the best quality Film Blowing Machines.
- We are united, innovative and brave to break the bottleneck of industry development, and gradually build and expand our global integrated supply and sales network and service center in the Shrinkable Film Making Machine field.
- Our team is dedicated to providing fast and responsive support to all of our customers.
- We are recognized by the industry for our integrity, our strength and the excellent quality of our Shrinkable Film Making Machine.
- We have a large inventory of machines ready to be shipped to our customers.
- Therefore, the performance and effects of our Shrinkable Film Making Machine is not inferior to imported product.
